[post_content] => The Tardito Rtary Blowing Machine model TP20/S is designed to blow new bottles with filtered air, to clean the inside from powder and any small particle, prior to the filling operation. This Semi-Automatic Sparging Machine with manual loading and unloading of the bottles, operates with Air or Gas injection. Machine is supplied mounted on wheels with braking device. The model TP is totally built-in stainless steel AISI 304, or in other specifically material approved for this use.

Output up to 700 bph. Standard voltage 220V-1F-50Hz.  $165 Extra charge to convert to 110V.

Manufacturer suggests using nitrogen or accurately pre-filtered, compressed air due to the contact with product. Non-filtered air may leave traces of contamination elements (i.e., mechanic oil droplets…) inside of bottles.

WORKING CYCLE

The operator places by hand the bottle upside down in one of the 20 positions on the central plate of the machine. The plate is turning with step-by-step motion.



TECHNICAL SPECIFICATIONS:

Voltage                                              220 V – 1phase – 50/60 Hz (Extra Charge to convert to 110V)

Installed Power                               0.25 kW

Main sizes                                         1000 x 1000 x h 750 mm

Weight                                               Kg 85



OPTIONS:

AISI 316 Stainless-Steel: Starting at $900.00 (Machine is normally built with AISI 304 Stainless Steel)

Additional Change Parts for Bottles: Starting at $650.00*

• Change Parts for additional round bottles are the cups for holding the bottles by the neck. Often, the same cups can be used for different bottles sizes, when the neck size is similar. Most standard bottles (750ml) can be accommodated with the same set of cups. Drawing/Specs can be emailed to us if needed so that we can estimate the number of additional cups which may be needed.

[post_title] => Tardito TP20 Semi-Automatic Sparger
[post_excerpt] => The TP20/S Rotary Blowing Machine uses filtered air or gas to clean bottles before filling. Semi-automatic, stainless steel, adjustable output up to 700 bph.
